DC Connector

First 1234567 Last1/13
Why Choose Us?

Rich Experience

Dongguan WS Electronic Technology Co., Ltd, is a professional manufacturer of OEM Connector and Cable Assembly with more than 18 years' experience.



Broad Market

The products are sold to all over the world: Europe, America, Middle East, Southeast, Africa and other countries and regions, it has been widely recognized and trusted by many customers.

Wide Product Range

Dongguan WS Electronic Technology Co., Ltd, Main products are DC Connectors, Earphone Connectors, Mobile Phone Charger connectors, Audio and Video Connector and Corresponding Cable Product. They are popular used in mobile phone, headset, car charger, LED light, electric toothbrush, beauty instrument, medical equipment.



Advanced Equipment

Company introduces first-class production equipment and testing equipment: high-speed precision automatic lathe and punching machine, original vertical injection molding machine, automatic assembly machine, high voltage tester, insertion force tester, salt spray tester, current load instrument, environmental tester, which is essential to ensure product quality, price, delivery time to meet customers' needs.



Definition of DC Connector





A DC connector (or DC plug, for one common type of connector) is an electrical connector for supplying direct current (DC) power. Compared to domestic AC power plugs and sockets, DC connectors have many more standard types that are not interchangeable. The dimensions and arrangement of DC connectors can be chosen to prevent accidental interconnection of incompatible sources and loads. Types vary from small coaxial connectors used to power portable electronic devices from AC adapters, to connectors used for automotive accessories and for battery packs in portable equipment.



XT60 Connector Gold Plated Connector With Cap With Sheath 30A DC 500V Heavy Duty Male And Female For Lipo Battery
Add to Inquiry
XT60 Connector Gold Plated Connector With Cap With Sheath 30A DC 500V Heavy D...

$ 0.63

The XT60 connector is a widely used high-load connector for power connections. This article will
5Pin 4Pin Male Micro USB Connector Copper MicroUSB Plug Mini USB Male MICRO 4P Welded Wire With Shell Plug-in Interface
Add to Inquiry
5Pin 4Pin Male Micro USB Connector Copper MicroUSB Plug Mini USB Male MICRO 4...

$ 0.03

The micro USB male connector is a widely used interface for data transfer and charging in various
DC044B 5.5mm DC Power Jack Horizontal Dc Power Socket For Sinking Plate Large Current Charging Female Connector
Add to Inquiry
DC044B 5.5mm DC Power Jack Horizontal Dc Power Socket For Sinking Plate Large...

$ 0.22

The DC044B Outlet is an innovative electrical device that offers numerous advantages, guaranteeing
GX12 4 Pin Male And Female Aviation Connector 16mm M12 L88-93 Circular Aviaton Plug And Socket Wire Panel Metal Connectors
Add to Inquiry
GX12 4 Pin Male And Female Aviation Connector 16mm M12 L88-93 Circular Aviato...

$ 0.44

In the world of aviation, reliable and secure connections are crucial for the safety and
XT30U-F XT30U-M XT30 Plug And Socket For Lithium Battery Production Male To Female Xt30 Connector Adapter
Add to Inquiry
XT30U-F XT30U-M XT30 Plug And Socket For Lithium Battery Production Male To F...

$ 0.58

The XT30 connector is an essential component in the field of lithium battery applications. Designed
DC Female Connector 38135 High Quality DC-083A Copper DC3.8 DC Charging Hole Power Jack Socket Connector 3A Short Circuit Socket
Add to Inquiry
DC Female Connector 38135 High Quality DC-083A Copper DC3.8 DC Charging Hole ...

$ 0.15

The DC38135 socket is an essential component of air-conditioned clothing, providing a convenient
First 1234567 Last1/13
Benefits of DC Connector



A DC connector is an electronic device used to convert the electrical energy from a DC power source into DC power suitable for charging devices. Here are several advantages of DC-to-DC converters:



Voltage Adaptability

DC connectors can convert the input voltage from a power source into an output voltage suitable for specific devices. This makes them well-suited for converting electrical energy between devices with different voltage requirements. For example, they can convert the 12V DC power from a car battery into 5V DC power suitable for charging a mobile phone.




Current Regulation

DC connector converters can also regulate the output current to meet the charging requirements of devices. This allows them to provide the appropriate charging current for different devices, ensuring charging safety and effectiveness.




Energy Conversion Efficiency

DC connectors typically have high energy conversion efficiency. They can convert input electrical energy into output electrical energy with high efficiency, reducing energy waste and loss. This helps improve energy utilization in devices and prolong battery life.




Versatility

DC connector can adapt to different input and output voltage requirements, making them versatile in various applications. They can be used for charging devices, electronic equipment, communication devices, automotive electronics, and more.





What is the Role of DC Connector?





DC Connectors will have current and voltage ratings specified by the manufacturer to ensure reliability in power delivery applications. The jack and plug of a standard DC Connector will typically feature two conductors.
One conductor is exposed and the second conductor is recessed, which helps prevent an accidental short between the two conductors.
Because barrel connectors are almost always used to supply power to an end application, there is virtually no risk of damaging other components by plugging a DC Connector into an incorrect port.



What Is the Color Code for Dc Connectors?




Function

label

Color

Positive (of a negative grounded) circuit

L+

Red

Negative (of a negative grounded) circuit

N

White

Positive (of a positive grounded) circuit

N

White

Negative (of a positive grounded) circuit

L-

Black



What Size is a DC Connector?



Generic plugs are often described by their inside diameter, such as 2.1 mm DC plugs.
After the two common 5.5 mm OD (Outer Diameter) plugs, the next-most common size is 3.5 mm OD with a 1.3 mm ID (Inner Diameter), usually about 9.5 mm in length, although both longer and shorter versions also exist.
These 3.5 mm OD plugs are normally used for lower voltages and currents.



Design Notes - DC Connector

Standardization
A variety of standards exist in the DC power connector category to cover specific connector types, such as coaxial and USB formats. No single standard covers the entire category.



Mounting type
Panel mount, through-hole mount soldered to the PCB, and mid-mount SMT are common options. Mounting type for a DC power jack to an end application varies depending on the application.



Mating cycles
Applications that require DC power connectors are often subject to frequent mating and unmating cycles, so these connectors are typically rated for thousands of cycles.

Positions

DC connectors typically have two positions (also referred to as poles or pins): positive and negative. Connecting the positive and negative poles correctly ensures that the electrical device receives the intended voltage and current, preventing potential damage to the device.

Dimensions

The dimensions of DC connectors can vary widely depending on the specific type and purpose of the connector.

Contacts

DC connectors have specific pin configurations to accommodate various functions, such as power delivery, data transfer, or additional features.

Material specifications

Materials used in DC connectors vary based on the type of connector, its intended application, and environmental considerations.



Common DC Connector Types


DC power connectors are common in daily life, such as cigarette lighter sockets and DC connectors for laptops. They come in numerous types, each designed for specific activities. Here is an overview of some important DC connector types.

Barrel Connector

Barrel connectors, also known as cylindrical connectors or coaxial power connectors, are considered the most common DC power connectors for their ease of manufacturing. They usually feature concentric barrels and center pins. Barrel connectors have varying outer diameters (OD), inner diameters (ID), and lengths of the metal sleeve, in which the most common sizes are 5.5 mm * 2.5 mm (OD * ID) and 5.5 mm * 2.1 mm, along with 9.5 mm as the typical length.
Standard coaxial power connectors do not require orientation when plugging in, facilitating the usage. However, they lack a balanced tolerance between the central pin and the inner sleeve, which can cause a loose connection. Consequently, some barrel connectors add locking threaded nuts, locking rings, or locking tabs to resist accidental unplugging.

DIN Connector

DIN connectors are a type of connector with a multi-pin design originally defined by the German Institute for Standards. Standard DIN connectors come in 3-pin to 8-pin versions and different pin layouts. The DIN connector has a miniaturized version called mini-DIN. These connectors are widely used in audio equipment, musical instruments, and lighting systems.

USB Connector

USB DC connectors initially gained popularity as power and data transfer connectors for computers. USB-A connectors find extensive usage in power-only applications not only for their prevalence. They are preferred as a typical connector to provide 5 VDC voltage. Micro USB connectors are used to charge mobile phones. USB-C connectors feature a more compact structure and eliminate the trouble of orientating, surpassing previous USB connectors. Moreover, they exceed the traditional limits by delivering voltages of up to 20 V. USB Type-C connectors are widely used in new smartphones and laptops.

Banana Connector

Banana connectors are characterized by their banana-shaped contact tips, which enhance connection and conductivity. Regular banana connectors are designed for low-voltage audio and video devices. However, they may not suit the power supply due to their incomplete insertion, lack of double insulation, and tendency to cause wrong connections. You'd better choose specialized banana plugs with enhanced features for power supplies.



When Do We Use DC Connector?



AC and DC are different from each other, but we use both types of current in our modern society because each has their own advantages and disadvantages, thus making them great for their own applications. AC current is better for the power flowing through our walls because it can be easily scaled up to extremely high voltages without the risk of overheating wires. The voltage running across those lines attached to giant steel towers often exceeds hundreds of thousands of volts, but won't lose too much of that voltage when it's transmitted over extremely long distances.



DC current doesn't do particularly well in this department—scaling it up involves a lot of heat and risk to power lines, and even scaled to high voltages only really has the ability to travel about a mile or two before it loses too much energy. If our homes ran on DC power rather than AC, we'd need to have power plants every couple of blocks or so to service a small number of people. Instead, since we use AC power, we can have one giant power plant that serves thousands of customers, and does so through the use of localized substations.



However, DC current has its advantages as well—it's actually far safer than AC power, and puts you at far lower of an injury risk if you accidentally shock yourself. Likewise, it's far more stable at lower voltage levels, which means it's great for powering our devices. DC circuits are generally far simpler to design, more reliable, produce less heat, and are more stable, which makes them great for electronics or other things which we plug into our walls.



And we're able to compromise and use both through devices known as rectifiers. A rectifier is a device which takes AC current from the wall and converts it into DC. Using other devices known as step-down converters or "buck" converters, we can then turn the higher voltage into low, stable numbers needed to power our devices smoothly and efficiently. In this way, both AC and DC current can actually work together in harmony.



XT60 Connector Gold Plated Connector With Cap With Sheath 30A DC 500V Heavy Duty Male And Female For Lipo Battery



The Considerations for Buying DC Connector

A few key specifications when deciding on an appropriate barrel connector is the inner pin and outer sleeve diameters.
Although a common clearance has yet to be standardized, the inner sleeve diameter, which interfaces with the inner pin, should be slightly larger than that of the mating pin. When it comes to the outer sleeve and mating connector, the clearance is not critical to the proper function of the connector because the mating connection to the outer sleeve is a cantilevered flat spring.
In addition to the inner pin and outer sleeve diameters, the depth of insertion is another DC Connector specification to note. A designer will often find that the jack insertion depth is less than the plug barrel length. This is because it is important to account for the depth of the chassis wall in certain installations.




Our Factory



Dongguan WS Electronic Technology Co., Ltd, Main products are DC Connectors, Earphone Connectors, Mobile Phone Charger connectors, Audio and Video Connector and Corresponding Cable Product. They are popular used in mobile phone, headset, car charger, LED light, electric toothbrush, beauty instrument, medical equipment. The products are sold to all over the world: Europe, America, Middle East, Southeast, Africa and other countries and regions, it has been widely recognized and trusted by many customers.

Company introduces first-class production equipment and testing equipment: high-speed precision automatic lathe and punching machine, original vertical injection molding machine, automatic assembly machine, high voltage tester, insertion force tester, salt spray tester, current load instrument, environmental tester, which is essential to ensure product quality, price, delivery time to meet customers' needs.



productcate-1-1



Ultimate FAQ Guide to DC Connector



Q: How do dc connectors work?

A: DC connectors typically have two positions (also referred to as poles or pins): positive and negative. Connecting the positive and negative poles correctly ensures that the electrical device receives the intended voltage and current, preventing potential damage to the device.

Q: What is the function of the DC connector?

A: DC power connectors are designed to supply direct current from a mains connection to a device and is typically used to power small to medium appliances. Although there are various types of DC Connector, the most common type is sometimes referred to as a Barrel Connector.

Q: What are the Advantages of DC Connectors?

A: DC Connectors have several advantages that make them widely used in various applications. A DC Connector is an electronic device used to convert the electrical energy from a DC power source into DC power suitable for charging devices.

Q: What does a DC Connector look like?

A: The standard dc barrel plug or jack has two conductors, one each for power and ground. Convention is for the center pin to be power and the outer sleeve to be ground, but reversing the connections is acceptable. Some power jack models include a third conductor which forms a switch with the outer sleeve conductor.

Q: What is the difference between AC and DC connectors?

A: Because DC power is a linear source, it is far more consistent and reliable. It doesn't bounce around and change direction like AC does. As such, most electronics rely on it. They use batteries as the primary source of DC. With that said, though, there are also a wide array of devices that use AC power instead: including household appliances, lamps, and more.

Q: Does DC connector into a wall?

A: DC current has its advantages as well—it's actually far safer than AC power, and puts you at far lower of an injury risk if you accidentally shock yourself. Likewise, it's far more stable at lower voltage levels, which means it's great for powering our devices. DC circuits are generally far simpler to design, more reliable, produce less heat, and are more stable, which makes them great for electronics or other things which we plug into our walls.

Q: What are the most common DC connectors?

A: Common examples of DC connectors include barrel connectors, coaxial power connectors, audio connectors, power jacks, and USB connectors. The development of DC connectors is closely tied to the development of electrical and electronic systems. The earliest forms of the DC connector date to the late 19th and early 20th centuries. With the rise of electronic devices in the mid-20th century, the need for specialized DC connectors increased.

Q: What are the benefits of using DC Connector?

A: Reliability: The use of DC power in telecom systems helps reduce power outage risks and increases network reliability.
Efficiency: DC power is more efficient than AC power because it does not waste energy in the form of heat.

Q: What is the use of DC connector?

A: A DC connector (or DC plug, for one common type of connector) is an electrical connector for supplying direct current (DC) power. Compared to domestic AC power plugs and sockets, DC connectors have many more standard types that are not interchangeable. The dimensions and arrangement of DC connectors can be chosen to prevent accidental interconnection of incompatible sources and loads.

Q: Can a DC connector be used for AC?

A: They will 'work' but the insulation rating may not be sufficient and you might get dangerous arcing. Even if the DC and AC voltage ratings are the same, a DC arc sustains itself better than AC so spacings should be higher with DC. Connectors are not specified for "AC" or "DC".

Q: What are the most common DC connectors?

A: Common examples of DC connectors include barrel connectors, coaxial power connectors, audio connectors, power jacks, and USB connectors. The development of DC connectors is closely tied to the development of electrical and electronic systems.

Q: Does DC Connector into a wall?

A: DC circuits are generally far simpler to design, more reliable, produce less heat, and are more stable, which makes them great for electronics or other things which we plug into our walls.

Q: What is the difference between AC and DC connectors?

A: Because DC power is a linear source, it is far more consistent and reliable. It doesn't bounce around and change direction like AC does. As such, most electronics rely on it. They use batteries as the primary source of DC.

Q: What does a DC Connector plug look like?

A: The standard dc barrel plug or jack has two conductors, one each for power and ground. Convention is for the center pin to be power and the outer sleeve to be ground, but reversing the connections is acceptable. Some power jack models include a third conductor which forms a switch with the outer sleeve conductor.

Q: How to Choose DC Connector?

A: In addition to selecting the connector pin and sleeve dimensions, the design engineer needs to also specify the mounting style of the dc power connector. Panel mounted connectors have the advantage of mounting almost anywhere on the product chassis, but do require wires to connect to the associated circuitry.

Q: Are all DC connectors the same?

A: Compared to domestic AC power plugs and sockets, DC connectors have many more standard types that are not interchangeable. The dimensions and arrangement of DC connectors can be chosen to prevent accidental interconnection of incompatible sources and loads.

Q: What is the use of DC connector?

A: A DC connector (or DC plug, for one common type of connector) is an electrical connector for supplying direct current (DC) power. Compared to domestic AC power plugs and sockets, DC connectors have many more standard types that are not interchangeable.

Q: What size is a DC connector?

A: Generic plugs are often described by their inside diameter, such as 2.1 mm DC plugs. After the two common 5.5 mm OD (Outer Diameter) plugs, the next-most common size is 3.5 mm OD with a 1.3 mm ID (Inner Diameter), usually about 9.5 mm in length, although both longer and shorter versions also exist.

Q: What are the most common DC connectors?

A: Common examples of DC connectors include barrel connectors, coaxial power connectors, audio connectors, power jacks, and USB connectors. The development of DC connectors is closely tied to the development of electrical and electronic systems.

As one of the leading dc connector manufacturers and suppliers in China, we warmly welcome you to wholesale high-grade dc connector made in China here from our factory. All customized products are with high quality and low price. For free sample, contact us now.
